Please contact us for more photos of 0313874009
| Part Number | 0313874009 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 575650 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 80 POS 2.54mm Solder ST Thru-Hole Carton |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 0313874009 |
| Datasheet download |  0313874009.pdf |
| Part Number | 0313874009 |
|---|---|
| Termination Method | Solder |
| Operating Temperature | -40 to 125 °C |
| Body Orientation | Straight |
| Gender | HDR |
| Housing Material | Polybutylene Terephthalate |
| Pitch | 2.54 mm |
| Contact Material | Copper Alloy |
| Product Dimensions | 66.68 x 32.68 x 21.55 mm |
| Lead Finish | Nickel |
| Mounting | Through Hole |
| Contact Plating | Gold Over Nickel |
| Housing Color | Gray |
| Product Depth | 32.68 mm |
| Product Height | 21.55 mm |
| Product Length | 66.68 mm |
| Replacement Part Number | PART-0313874009 |
| Weight | Contact us |
| Country of Origin | - |
