Please contact us for more photos of 0099990989
| Part Number | 0099990989 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 599310 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 5 POS 2.5mm Solder ST Thru-Hole Bag |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 0099990989 |
| Datasheet download |  0099990989.pdf |
| Part Number | 0099990989 |
|---|---|
| Product Dimensions | 14.9 x 4.9 x 5.9 mm |
| Pitch | 2.5 mm |
| Rad Hard | No |
| Termination Method | Solder |
| Housing Color | Natural |
| Housing Material | Nylon |
| Contact Plating | Tin Over Copper |
| Body Orientation | Straight |
| Mounting | Through Hole |
| Contact Material | Brass |
| Operating Temperature | -40 to 105 °C |
| Gender | HDR |
| Lead Finish | Tin |
| Product Depth | 4.9 mm |
| Product Height | 5.9 mm |
| Product Length | 14.9 mm |
| Replacement Part Number | PART-0099990989 |
| Weight | Contact us |
| Country of Origin | - |
