Please contact us for more photos of N25Q512A13GF840F
| Part Number | N25Q512A13GF840F |
|---|---|
| Manufacturer | Micron |
| Quantity in stock | 601790 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | NOR Flash Serial-SPI 3V 512Mbit 512M 256M 128M x 1bit 2bit 4bit 8ns 8-Pin DFN T R |
| Category | Memory IC |
| Family | Flash IC |
| ROHS Compliant | Yes |
| MSL Level | N25Q512A13GF840F |
| Datasheet download |  N25Q512A13GF840F.pdf |
| Part Number | N25Q512A13GF840F |
|---|---|
| Operating Temperature | -40 to 85 °C |
| Maximum Operating Supply Voltage | 3.6 V |
| Command Compatible | Yes |
| Cell Type | NOR |
| Architecture | Sectored |
| Block Organization | Symmetrical |
| Number of Bits per Word | 1/2/4 Bit |
| Typical Operating Supply Voltage | 3 V |
| Maximum Erase Time | 3/Sector s |
| Timing Type | Synchronous |
| Screening Level | Industrial |
| Supplier Package | DFN |
| Product Dimensions | 8 x 6 x 0.95(Max) |
| Pin Count | 8 |
| Max Processing Temp | 260 |
| Location Of Boot Block | Bottom|Top |
| Boot Block | Yes |
| Erase Suspend/Resume Modes Support | Yes |
| Simultaneous Read/Write Support | No |
| ECC Support | No |
| Maximum Random Access Time | 8 ns |
| Minimum Operating Supply Voltage | 2.7 V |
| Page Size | 256 byte |
| Interface Type | Serial-SPI |
| Maximum Operating Current | 20 mA |
| Number of Words | 512/256/128 m |
| Maximum Programming Time | 5/Page ms |
| Support of Page Mode | No |
| Program Current | 20 mA |
| Rad Hard | No |
| Sector Size | 64 x 1024 KB |
| Mounting | Surface Mount |
| Density | 512 Mb |
| Programming Voltage | 2.7 to 3.6 V |
| Package | 8DFN |
| Replacement Part Number | PART-N25Q512A13GF840F |
| Weight | Contact us |
| Country of Origin | - |
