Please contact us for more photos of DSPIC30F3012-20I SO
| Part Number | DSPIC30F3012-20I SO |
|---|---|
| Manufacturer | Microchip |
| Quantity in stock | 824890 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 16-bit dsPIC30 dsPIC RISC 24KB Flash 3.3V 5V 18-Pin SOIC W Tube |
| Category | Microcontrollers MCU IC |
| Family | 16 Bit Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | DSPIC30F3012-20I SO |
| Datasheet download |  DSPIC30F3012-20I SO.pdf |
| Part Number | DSPIC30F3012-20I SO |
|---|---|
| Number of Timers | 3 |
| Program Memory Type | Flash |
| Minimum Operating Supply Voltage | 2.5 V |
| Pin Count | 18 |
| Supplier Package | SOIC W |
| Max Processing Temp | 260 |
| On-Chip ADC | 8-chx12-bit |
| Operating Supply Voltage | 3.3|5 V |
| Number of Programmable I/Os | 12 |
| Rad Hard | No |
| Device Core | dsPIC |
| Program Memory Size | 24 KB |
| RAM Size | 2 KB |
| Interface Type | I2C/SPI/UART |
| Product Dimensions | 11.53 x 7.49 x 2.31 mm |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Instruction Set Architecture | RISC |
| Operating Temperature | -40 to 85 °C |
| Maximum Operating Supply Voltage | 5.5 V |
| Maximum Speed | 20 MHz |
| Screening Level | Industrial |
| Watchdog | 1 |
| Data Bus Width | 16 |
| Package | 18SOIC W |
| Replacement Part Number | PART-DSPIC30F3012-20I SO |
| Weight | Contact us |
| Country of Origin | - |
