Please contact us for more photos of AT90USB646-MU
| Part Number | AT90USB646-MU |
|---|---|
| Manufacturer | Microchip |
| Quantity in stock | 343660 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 8-bit AT90 AVR RISC 64KB Flash 3.3V 5V 64-Pin QFN EP |
| Category | Microcontrollers MCU IC |
| Family | 8 Bit Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | AT90USB646-MU |
| Datasheet download |  AT90USB646-MU.pdf |
| Part Number | AT90USB646-MU |
|---|---|
| Data Bus Width | 8 Bit |
| On-Chip ADC | 8-chx10-bit |
| Program Memory Type | Flash |
| Minimum Operating Supply Voltage | 2.7 V |
| Number of Timers | 4 |
| Number of Programmable I/Os | 48 |
| Screening Level | Industrial |
| Device Core | AVR |
| Supplier Package | QFN EP |
| RAM Size | 4 KB |
| Maximum Speed | 20 MHz |
| Lead Finish | Matte Tin |
| Watchdog | 1 |
| Maximum Expanded Memory Size | 64 KB |
| MSL Level | 3 |
| Rad Hard | No |
| Mounting | Surface Mount |
| Program Memory Size | 64 KB |
| Operating Supply Voltage | 3.3|5 V |
| Product Dimensions | 9 x 9 x 0.95 mm |
| Analog Comparators | 1 |
| Interface Type | SPI/TWI/USART/USB |
| Max Processing Temp | 260 |
| Maximum Operating Supply Voltage | 5.5 V |
| Operating Temperature | -40 to 85 °C |
| Pin Count | 64 |
| Instruction Set Architecture | RISC |
| Package | 64QFN EP |
| Replacement Part Number | PART-AT90USB646-MU |
| Weight | Contact us |
| Country of Origin | - |
