Please contact us for more photos of MAX97220EETE+T
| Part Number | MAX97220EETE+T |
|---|---|
| Manufacturer | Maxim Integrated |
| Quantity in stock | 499470 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Audio Amp Headphone 2-CH Stereo 0.125W 16-Pin TQFN EP T R |
| Category | Amplifiers IC |
| Family | Audio Amplifier |
| ROHS Compliant | Yes |
| MSL Level | MAX97220EETE+T |
| Datasheet download |  MAX97220EETE+T.pdf |
| Part Number | MAX97220EETE+T |
|---|---|
| Power Supply Type | Single |
| Typical Output Power x Channels @ Load | 0.125x2@32Ohm W |
| Maximum Single Supply Voltage | 5.5 V |
| Pin Count | 16 |
| Typical Single Supply Voltage | 3.3|5 V |
| Input Signal Type | Differential |
| Output Type | 2-Channel Stereo |
| Operating Temperature | -40 to 85 °C |
| Maximum Power Dissipation | 1666.7 mW |
| Supplier Package | TQFN EP |
| Minimum Single Supply Voltage | 2.5 V |
| Screening Level | Extended Industrial |
| Rail to Rail | No |
| Rad Hard | No |
| Moisture Sensitivity Level | 1 |
| Maximum Supply Current | 9@5V mA |
| Maximum Load Resistance | 32 Ohm |
| Total Harmonic Distortion Noise | 0.0035@32Ohm@20mW % |
| Minimum CMRR | 70 dB |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Function | Headphone |
| Maximum Processing Temperature | 260 °C |
| Typical Supply Current | 5@5V mA |
| Typical Voltage Gain | 6 dB |
| Package Dimensions | 3 x 3 x 0.73 mm |
| Output Signal Type | Single |
| Typical PSRR | 90 dB |
| Package | 16TQFN EP |
| Replacement Part Number | PART-MAX97220EETE+T |
| Weight | Contact us |
| Country of Origin | - |
