MAX797CSE+ Maxim Integrated

MAX797CSE+ Images

Please contact us for more photos of MAX797CSE+

Part Number MAX797CSE+
Manufacturer Maxim Integrated
Quantity in stock 400860 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Conv DC-DC Single Step Down 4.5V to 30V 16-Pin SOIC N
Category Power Management IC
Family DC to DC Converter
ROHS Compliant Yes
MSL Level MAX797CSE+
Datasheet download MAX797CSE+.pdf
Request Quotation for MAX797CSE+

MAX797CSE+ Specifications

Part Number MAX797CSE+
Switching Frequency 330|175 kHz
Load Regulation 2.5 %
Maximum Input Voltage 30 V
Switching Regulator Yes
Product Dimensions 10 x 4 x 1.5 mm
Lead Finish Matte Tin
Screening Level Commercial
Rad Hard No
Output Voltage 2.5 to 6|3.3|5 V
Type Step Down
Maximum Output Current 10 A
Number of Outputs 1
Output Type Adjustable|Fixed
Minimum Input Voltage 4.5 V
Line Regulation 0.06 %/V
Max Processing Temp 260|300
Operating Supply Voltage 4.5 to 30 V
Mounting Surface Mount
Supplier Package SOIC N
Efficiency 96 %
Pin Count 16
MSL Level 1
Operating Temperature 0 to 70 °C
Package 16SOIC N
Replacement Part Number PART-MAX797CSE+
Weight Contact us
Country of Origin -
