Please contact us for more photos of MAX4377HAUA+T
| Part Number | MAX4377HAUA+T |
|---|---|
| Manufacturer | Maxim Integrated |
| Quantity in stock | 864770 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | SP Amp Current Sense Amp Dual 28V 8-Pin uMAX T R |
| Category | Amplifiers IC |
| Family | SP Amplifier |
| ROHS Compliant | Yes |
| MSL Level | MAX4377HAUA+T |
| Datasheet download |  MAX4377HAUA+T.pdf |
| Part Number | MAX4377HAUA+T |
|---|---|
| Operating Temperature | -40 to 125 °C |
| Minimum PSRR | 66 |
| Pin Count | 8 |
| Maximum Voltage Gain | 26.02 dB |
| Supplier Package | uMAX |
| Minimum CMRR | 90 dB |
| Product Dimensions | 3.1 x 3.1 x 0.95 mm |
| Maximum Single Supply Voltage | 28 V |
| Screening Level | Automotive |
| Number of Channels per Chip | 2 |
| Rad Hard | No |
| Type | Current Sense Amplifier |
| Power Supply Type | Single |
| Minimum Single Supply Voltage | 3 V |
| Max Processing Temp | 260|300 |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Maximum Supply Current | 2@28 mA |
| Rail to Rail | No |
| Lead Finish | Matte Tin |
| Maximum Input Bias Current | 60@28V@-40C to 125C |
| Package | 8uMAX |
| Replacement Part Number | PART-MAX4377HAUA+T |
| Weight | Contact us |
| Country of Origin | - |
