Please contact us for more photos of MAX3469ESA+
| Part Number | MAX3469ESA+ |
|---|---|
| Manufacturer | Maxim Integrated |
| Quantity in stock | 323600 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Single Transmitter Receiver RS-422 RS-485 8-Pin SOIC N |
| Category | Communication |
| Family | Bus Line Transceiver |
| ROHS Compliant | Yes |
| MSL Level | MAX3469ESA+ |
| Datasheet download |  MAX3469ESA+.pdf |
| Part Number | MAX3469ESA+ |
|---|---|
| Lead Finish | Matte Tin |
| Typical Single Supply Voltage | 5 |
| Driving Mode | 3-State |
| ESD Protection | Yes |
| Mounting | Surface Mount |
| Screening Level | Extended |
| Data Rate | 40 |
| Power Supply Type | Single |
| Number of Receiver Enables | 1 |
| Number of Transmitters | 1 |
| Interface Standards | EIA/TIA-422-B|EIA/TIA-485-A|RS-422|RS-485|V.11|X.27 |
| Pin Count | 8 |
| MSL Level | 1 |
| Maximum Supply Current | 4 |
| Function | Line Transceiver |
| Maximum Single Supply Voltage | 5.25 |
| Max Processing Temp | 260|300 |
| Transmitter Signal Type | Differential |
| Transmitter Communication Type | RS-422|RS-485 |
| Receiver Signal Type | Differential |
| Number of Receivers per Line | 40@RS-422|128@RS-485 |
| Number of Drivers per Line | 4@RS-422|128@RS-485 |
| Receiver Communication Type | RS-422|RS-485 |
| Number of Receivers | 1 |
| Number of Transceivers | 1 |
| Number of Transmitter Enables | 1 |
| Minimum Single Supply Voltage | 4.75 |
| Product Dimensions | 5 x 4 x 1.5 mm |
| Rad Hard | No |
| Supplier Package | SOIC N |
| Data Transmission Topology | Multidrop|Multipoint |
| Operating Temperature | -40 to 85 °C |
| Package | 8SOIC N |
| Replacement Part Number | PART-MAX3469ESA+ |
| Weight | Contact us |
| Country of Origin | - |
