Please contact us for more photos of MAX1270AEAI+T
| Part Number | MAX1270AEAI+T |
|---|---|
| Manufacturer | Maxim Integrated |
| Quantity in stock | 526740 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single SAR 100ksps 12-bit Serial 28-Pin SSOP T R |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | MAX1270AEAI+T |
| Datasheet download |  MAX1270AEAI+T.pdf |
| Part Number | MAX1270AEAI+T |
|---|---|
| Number of ADCs | 1 |
| Maximum Single Supply Voltage | 5.25 V |
| Typical Power Dissipation | 30 mW |
| Supplier Package | SSOP |
| Full Scale Error | ±7 LSB |
| Polarity of Input Voltage | Unipolar|Bipolar |
| Rad Hard | No |
| Product Dimensions | 10.33 x 5.38 x 1.78 mm |
| Sampling Rate | 100 ksps |
| Operating Temperature | -40 to 85 °C |
| Screening Level | Extended Industrial |
| Input Signal Type | Single-Ended |
| Voltage Supply Source | Single |
| Input Voltage | 5/10|±5/±10 V |
| Single-Ended Input | Yes |
| Max Processing Temp | 260|300 |
| Integral Nonlinearity Error | ±0.5 LSB |
| Sample and Hold | Yes |
| Minimum Single Supply Voltage | 4.75 V |
| Mounting | Surface Mount |
| Input Type | Voltage |
| Pin Count | 28 |
| Differential Nonlinearity | ±1 LSB |
| Differential Input | No |
| Number of Analog Inputs | 8 |
| Voltage Reference | Internal|External |
| Typical Single Supply Voltage | 5 V |
| MSL Level | 1 |
| Digital Interface Type | Serial (3-Wire, SPI, QSPI, Microwire) |
| Maximum Power Dissipation | 762 mW |
| Lead Finish | Matte Tin |
| Package | 28SSOP |
| Replacement Part Number | PART-MAX1270AEAI+T |
| Weight | Contact us |
| Country of Origin | - |
