| Part Number | HCPL-0201 |
|---|---|
| Manufacturer | Broadcom |
| Quantity in stock | 814510 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Optocoupler Logic-Out Totem-Pole DC-IN 1-CH 8-Pin SOIC Tube |
| Category | Optoelectronics |
| Family | OptoCouplers |
| ROHS Compliant | Yes |
| MSL Level | HCPL-0201 |
| Datasheet download |  HCPL-0201.pdf |
| Part Number | HCPL-0201 |
|---|---|
| Output Type | Totem-Pole |
| Maximum Forward Current | 10 mA |
| Maximum Reverse Voltage | 5 V |
| Mounting | Surface Mount |
| Typical Fall Time | 0.007 us |
| Input Type | DC |
| Lead Finish | Tin/Lead |
| Product Dimensions | 5.08 x 3.94 x 3.18 mm |
| Maximum Baud Rate | MBd |
| MSL Level | 1 |
| Pin Count | 8 |
| Direction Type | Uni-Directional |
| Supplier Package | SOIC |
| Maximum Power Dissipation | 210 mW |
| Logic Gate Type | AND Schmitt |
| Maximum Propagation Delay Time | 300 ns |
| Maximum Forward Voltage | 1.7 V |
| Max Processing Temp | 260 |
| Operating Temperature | -40 to 85 °C |
| Rad Hard | No |
| Package | 8SOIC |
| Replacement Part Number | PART-HCPL-0201 |
| Weight | Contact us |
| Country of Origin | - |
