T520C337M2R5ATE015 KEMET

T520C337M2R5ATE015 Images

Please contact us for more photos of T520C337M2R5ATE015

Part Number T520C337M2R5ATE015
Manufacturer KEMET
Quantity in stock 162230 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Cap Tant Solid 330uF 2.5V C CASE 20% (6 X 3.2 X 2.5mm) SMD 6032-28 0.015 Ohm 105\u00b0C T R
Category Capacitors
Family Capacitor Tantalum Solid SMT
ROHS Compliant Yes
MSL Level T520C337M2R5ATE015
Datasheet download T520C337M2R5ATE015.pdf
Request Quotation for T520C337M2R5ATE015

T520C337M2R5ATE015 Specifications

Part Number T520C337M2R5ATE015
Construction Flat
Lead Finish Matte Tin
Product Dimensions 6 x 3.2 x 2.5 mm
Polarity Polar
Mounting Surface Mount
Equivalent Series Resistance 0.015 Ohm
Dissipation Factor 8 %
Case Code C
Capacitance Value 330 uF
Voltage(DC) 2.5 V
MSL Level 3
Operating Temperature -55 to 105 °C
Case Size 6032-28
Package/Case 6032-28,C
Leakage Current 82.5 uA
Rad Hard No
Tolerance 20 %
Case Style Molded
Max Processing Temp 260
Product Depth 3.2 mm
Product Height 2.5 mm
Product Length 6 mm
Replacement Part Number PART-T520C337M2R5ATE015
Weight Contact us
Country of Origin -
