Please contact us for more photos of T520C337M004ATE025
| Part Number | T520C337M004ATE025 |
|---|---|
| Manufacturer | KEMET |
| Quantity in stock | 762780 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 330uF 4V C CASE 20% (6 X 3.2 X 2.5mm) SMD 6032-28 0.025 Ohm 105\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | T520C337M004ATE025 |
| Datasheet download |  T520C337M004ATE025.pdf |
| Part Number | T520C337M004ATE025 |
|---|---|
| Construction | Flat |
| Product Dimensions | 6 x 3.2 x 2.5 mm |
| Lead Finish | Matte Tin |
| Rad Hard | No |
| Mounting | Surface Mount |
| Case Style | Molded |
| Leakage Current | 132 uA |
| Capacitance Value | 330 uF |
| Polarity | Polar |
| Case Code | C |
| MSL Level | 3 |
| Voltage(DC) | 4 V |
| Dissipation Factor | 8 % |
| Equivalent Series Resistance | 0.025 Ohm |
| Operating Temperature | -55 to 105 °C |
| Max Processing Temp | 260 |
| Package/Case | 6032-28,C |
| Tolerance | 20 % |
| Case Size | 6032-28 |
| Product Depth | 3.2 mm |
| Product Height | 2.5 mm |
| Product Length | 6 mm |
| Replacement Part Number | PART-T520C337M004ATE025 |
| Weight | Contact us |
| Country of Origin | - |
