Please contact us for more photos of SMR5683G100J03L4BULK
| Part Number | SMR5683G100J03L4BULK |
|---|---|
| Manufacturer | KEMET |
| Quantity in stock | 667170 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.068uF 100V PPS 2% (7.2 X 4.5 X 9mm) Radial 5mm 150\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | SMR5683G100J03L4BULK |
| Datasheet download |  SMR5683G100J03L4BULK.pdf |
| Part Number | SMR5683G100J03L4BULK |
|---|---|
| Mounting | Through Hole |
| Termination Style | Radial |
| Pin Count | 2 |
| Construction | Radial |
| Tolerance | 2 % |
| Lead Pitch For Radial | 5 mm |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Package/Case | 7.2(Max) X 4.5(Max) X 9(Max) |
| Product Dimensions | 7.2(Max) x 4.5(Max) x 9(Max) |
| Lead Finish | Tin |
| Supplier Package | Radial |
| Dielectric Material | PPS |
| Voltage(DC) | 100 V |
| Seated Plane Height | 9 mm |
| Operating Temperature | -55 to 150 °C |
| Capacitance Value | 0.068 uF |
| Product Depth | 4.5(Max) mm |
| Product Height | 9(Max) mm |
| Product Length | 7.2(Max) mm |
| Replacement Part Number | PART-SMR5683G100J03L4BULK |
| Weight | Contact us |
| Country of Origin | - |
