Please contact us for more photos of SM23B274K102BM
| Part Number | SM23B274K102BM |
|---|---|
| Manufacturer | KEMET |
| Quantity in stock | 842840 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | CERAMIC CAP 0.27UF 10% 1000V X7R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | SM23B274K102BM |
| Datasheet download |  SM23B274K102BM.pdf |
| Part Number | SM23B274K102BM |
|---|---|
| Construction | Flat |
| Operating Temperature | -55 to 125 °C |
| Mounting | Surface Mount |
| Case Style | Ceramic Chip |
| Family | SM23 |
| Voltage(DC) | 1 kV |
| Termination Style | J-Lead |
| Military Standard | MIL-PRF-49467 |
| Dielectric | X7R |
| Rad Hard | No |
| Capacitance Value | 0.27 uF |
| Packaging | Tray |
| Lead Free | Yes |
| Package/Case | 3530 |
| Case Size | 3530 |
| Tolerance | 10 % |
| Product Depth | 7.62 mm |
| Product Height | 5.59 mm |
| Product Length | 8.89 mm |
| Replacement Part Number | PART-SM23B274K102BM |
| Weight | Contact us |
| Country of Origin | - |
