Please contact us for more photos of PHE850ED5680MD17R06L2
| Part Number | PHE850ED5680MD17R06L2 |
|---|---|
| Manufacturer | KEMET |
| Quantity in stock | 467140 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.068uF 1250V PP 20% (26 X 7 X 16.5mm) Radial 22.5mm 110\u00b0C Tray |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | PHE850ED5680MD17R06L2 |
| Datasheet download |  PHE850ED5680MD17R06L2.pdf |
| Part Number | PHE850ED5680MD17R06L2 |
|---|---|
| Capacitance Value | 0.068 uF |
| Rad Hard | No |
| Voltage(DC) | 1.25 kV |
| Mounting | Through Hole |
| Tolerance | 20 % |
| Dielectric | PP |
| Termination Style | Radial |
| Package/Case | 26(Max) X 7(Max) X 16.5(Max) |
| Lead Pitch For Radial | 22.5 mm |
| Dielectric Material | |
| Operating Temperature | -55 to 110 °C |
| Product Dimensions | 26 x 7 x 16.5 mm |
| Seated Plane Height | 16.5 mm |
| Product Depth | 7(Max) mm |
| Product Height | 16.5(Max) mm |
| Product Length | 26(Max) mm |
| Replacement Part Number | PART-PHE850ED5680MD17R06L2 |
| Weight | Contact us |
| Country of Origin | - |
