MDSM15PEZ10VR22 ITT Interconnect Solutions

MDSM15PEZ10VR22 Images

Please contact us for more photos of MDSM15PEZ10VR22

Part Number MDSM15PEZ10VR22
Manufacturer ITT Interconnect Solutions
Quantity in stock 534670 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Conn D-Subminiature PIN 15 POS 1.27mm Solder RA Thru-Hole 15 Terminal 1 Port Tube
Category Connectors
Family Connector D-Subminiature
ROHS Compliant Yes
MSL Level MDSM15PEZ10VR22
Datasheet download MDSM15PEZ10VR22.pdf
Request Quotation for MDSM15PEZ10VR22

MDSM15PEZ10VR22 Specifications

Part Number MDSM15PEZ10VR22
Termination Method Solder
Operating Temperature -55 to 125 °C
Gender PIN
Product Dimensions 23.7 x 18.1 x 8 mm
Body Orientation Right Angle
Mounting Through Hole
Lead Finish Tin
Housing Material Steel
Pitch 1.27 mm
Rad Hard No
Max Processing Temp 255
Contact Material Copper Alloy
Contact Plating Gold Over Palladium Nickel
Product Depth 18.1 mm
Product Height 8 mm
Product Length 23.7 mm
Replacement Part Number PART-MDSM15PEZ10VR22
Weight Contact us
Country of Origin -
