74LVC14APW DG,118 Nexperia

74LVC14APW DG,118 Images

Please contact us for more photos of 74LVC14APW DG,118

Part Number 74LVC14APW DG,118
Manufacturer Nexperia
Quantity in stock 273310 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Inverter Schmitt Trigger 6-Element CMOS 14-Pin TSSOP T R
Category Logic & Timing IC
Family Logic ICs
ROHS Compliant Yes
MSL Level 74LVC14APW DG,118
Datasheet download 74LVC14APW DG,118.pdf
Request Quotation for 74LVC14APW DG,118

74LVC14APW DG,118 Specifications

Part Number 74LVC14APW DG,118
Product Dimensions 5.1 x 4.5 x 0.95 mm
Logic Family LVC
Pin Count 14
Maximum Low Level Output Current 24 mA
Typical Quiescent Current 0.1 uA
Fabrication Technology CMOS
Typical Operating Supply Voltage 1.8|2.5|3.3 V
Minimum Operating Supply Voltage 1.2 V
Output Type Schmitt Trigger
Input Type Schmitt Trigger
Maximum Operating Supply Voltage 3.6 V
Logic Function Inverter Schmitt Trigger
Maximum High Level Output Current -24 mA
Maximum Quiescent Current 40 uA
Rad Hard No
Mounting Surface Mount
Number of Elements per Chip 6
Operating Temperature -40 to 125 °C
Supplier Package TSSOP
Maximum Propagation Delay Time @ Maximum CL [email protected]|[email protected] ns
Propagation Delay Test Condition 50 pF
Package 14TSSOP
Replacement Part Number PART-74LVC14APW DG,118
Weight Contact us
Country of Origin -
