Please contact us for more photos of S9091-46R
| Part Number | S9091-46R |
|---|---|
| Manufacturer | Harwin |
| Quantity in stock | 103540 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | EZ-Board Socket, SMT, for mating pin \u00d80.8 to 1.5mm |
| Category | Connectors |
| Family | Connector Contacts |
| ROHS Compliant | Yes |
| MSL Level | S9091-46R |
| Datasheet download |  S9091-46R.pdf |
| Part Number | S9091-46R |
|---|---|
| Family | S9091-46R |
| Packaging | Tape and Reel |
| Contact Plating | Tin Over Nickel |
| Connector Type | Connector Circular |
| Contact Type | Signal |
| Maximum Current Rating | 5 A |
| Gender | SKT |
| Series Name | S9091-46R |
| Rad Hard | No |
| Termination Method | Solder |
| Mounting | Surface Mount |
| Lead Free | Yes |
| Operating Temperature | -40 to 105 °C |
| Maximum Contact Resistance | 20 MOhm |
| Body Orientation | Straight |
| Shielded | No |
| Product Depth | 2 mm |
| Product Height | 0.2 mm |
| Replacement Part Number | PART-S9091-46R |
| Weight | Contact us |
| Country of Origin | - |
