Please contact us for more photos of S1711-46R
| Part Number | S1711-46R |
|---|---|
| Manufacturer | Harwin |
| Quantity in stock | 691430 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | EZ-Shield Clip, SMT, Midi, Beryllium Copper, tin, Tape & Reeled |
| Category | Connectors |
| Family | Cable Accessories |
| ROHS Compliant | Yes |
| MSL Level | S1711-46R |
| Datasheet download |  S1711-46R.pdf |
| Part Number | S1711-46R |
|---|---|
| Lead Finish | 100% Tin over Nickel |
| Mounting | Surface Mount (SMT) |
| MSL Level | 1 |
| Contact Plating | 100% Tin over Nickel |
| Type | EZ-BoardWare (PCB Hardware) mm |
| Body Orientation | Vertical |
| Max Processing Temp | 260 |
| Product Dimensions | 8.79 x 2.28 x 3.85 mm |
| Rad Hard | No |
| Operating Temperature | -40 to +105 °C |
| For Use With | 0.17mm to 0.3mm RFI Shields |
| Contact Material | Beryllium Copper |
| Product Depth | 2.28 mm |
| Product Height | 3.85 mm |
| Product Length | 8.8 mm |
| Replacement Part Number | PART-S1711-46R |
| Weight | Contact us |
| Country of Origin | - |
