Part Number | M80-8672622 |
---|---|
Manufacturer | Harwin |
Quantity in stock | 806760 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Datamate L-Tek DIL Male Vertical 3mm PC Tail Connector, latched, selective gold + tin lead, 13+13 contacts |
Category | Connectors |
Family | Connector Headers and PCB Receptacles |
ROHS Compliant | Yes |
MSL Level | M80-8672622 |
Datasheet download | M80-8672622.pdf |
Part Number | M80-8672622 |
---|---|
Body Orientation | Vertical |
Color | Black |
Rad Hard | No |
Contact Material | Phosphor Bronze |
Max Processing Temp | 235 |
Housing Material | PBT |
Type | 2.00 Pitch Datamate J-Tek mm |
Number of Contacts | 26 |
Mounting | PC Tail / Throughboard |
Termination Method | Solder |
Pitch | 2 mm |
Contact Plating | Gold |
Lead Finish | Tin/Lead |
Pin Count | 26 |
MSL Level | 1 |
Operating Temperature | -55 to +125 °C |
Product Dimensions | 30.1 x 5.98 x 5.56 |
Gender | M |
Housing Color | Black |
Product Depth | 5.98 mm |
Product Height | 5.56 mm |
Product Length | 30.1 mm |
Replacement Part Number | PART-M80-8672622 |
Weight | Contact us |
Country of Origin | - |
