Please contact us for more photos of H2175-01
| Part Number | H2175-01 |
|---|---|
| Manufacturer | Harwin |
| Quantity in stock | 541230 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | \u00d81mm Terminal Pin, 5.0mm high, for 1.6mm panel thickness, tin |
| Category | Connectors |
| Family | Connector Terminals |
| ROHS Compliant | Yes |
| MSL Level | H2175-01 |
| Datasheet download |  H2175-01.pdf |
| Part Number | H2175-01 |
|---|---|
| Product Dimensions | 1.78 mm |
| Contact Plating | 100% Tin over Nickel |
| Gender | M |
| Body Material | Brass |
| Body Orientation | Vertical |
| Rad Hard | No |
| Mounting | PC Tail / Throughboard |
| Contact Material | Brass |
| Type | Hardware - Terminal mm |
| Lead Finish | 100% Tin over Nickel |
| Plating | Tin |
| Operating Temperature | -40 to +105 °C |
| Number of Contacts | 1 |
| Product Depth | 1.78 mm |
| Product Length | 6.98 |
| Replacement Part Number | PART-H2175-01 |
| Weight | Contact us |
| Country of Origin | - |
