Please contact us for more photos of ZXTN2020FTA
| Part Number | ZXTN2020FTA |
|---|---|
| Manufacturer | Diodes Incorporated |
| Quantity in stock | 432620 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans GP BJT NPN 100V 4A 3-Pin SOT-23 T R |
| Category | Discrete Semiconductor |
| Family | Bipolar Transistor |
| ROHS Compliant | Yes |
| MSL Level | ZXTN2020FTA |
| Datasheet download |  ZXTN2020FTA.pdf |
| Part Number | ZXTN2020FTA |
|---|---|
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Product Dimensions | 3.04 x 1.4 x 1.02 mm |
| Supplier Package | SOT-23 |
| Pin Count | 3 |
| MSL Level | 1 |
| Maximum Base Emitter Saturation Voltage | 1.05@400mA@4A V |
| Maximum Collector Emitter Voltage | 100 V |
| Maximum Collector Emitter Saturation Voltage | 0.03@[email protected]|0.05@100mA@1A|0.105@100mA@2A|0.15@400mA@4A V |
| Maximum Power Dissipation | 1560 mW |
| Maximum Collector Base Voltage | 160 V |
| Maximum DC Collector Current | 4 A |
| Minimum DC Current Gain | 100@10mA@2V|100@1A@2V|35@4A@2V |
| Rad Hard | No |
| Operating Temperature | -55 to 150 °C |
| Type | NPN |
| Max Processing Temp | 260 |
| Maximum Emitter Base Voltage | 7 V |
| Package | 3SOT-23 |
| Replacement Part Number | PART-ZXTN2020FTA |
| Weight | Contact us |
| Country of Origin | - |
