Please contact us for more photos of STB13007DT4
| Part Number | STB13007DT4 |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 241890 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans GP BJT NPN 400V 8A 3-Pin(2+Tab) D2PAK T R |
| Category | Discrete Semiconductor |
| Family | Bipolar Transistor |
| ROHS Compliant | Yes |
| MSL Level | STB13007DT4 |
| Datasheet download |  STB13007DT4.pdf |
| Part Number | STB13007DT4 |
|---|---|
| Lead Finish | Matte Tin |
| Product Dimensions | 10.4 x 9.35 x 4.6 mm |
| Maximum Collector Base Voltage | 700 V |
| Maximum Collector Emitter Voltage | 400 V |
| Mounting | Surface Mount |
| Pin Count | 3 |
| MSL Level | 1 |
| Minimum DC Current Gain | 18@2A@5V|8@5A@5V |
| Maximum Collector Emitter Saturation Voltage | [email protected]@2A|1.5@1A@5A|2@2A@8A V |
| Maximum Power Dissipation | 80000 mW |
| Maximum Base Emitter Saturation Voltage | [email protected]@2A|1.6@1A@5A V |
| Rad Hard | No |
| Type | NPN |
| Supplier Package | D2PAK |
| Max Processing Temp | 245 |
| Maximum Emitter Base Voltage | 9 V |
| Maximum DC Collector Current | 8 A |
| Operating Temperature | -65 to 150 °C |
| Package | 3D2PAK |
| Replacement Part Number | PART-STB13007DT4 |
| Weight | Contact us |
| Country of Origin | - |
