Please contact us for more photos of KSP2222ATF
| Part Number | KSP2222ATF |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Quantity in stock | 761840 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans GP BJT NPN 40V 0.6A 3-Pin TO-92 T R |
| Category | Discrete Semiconductor |
| Family | Bipolar Transistor |
| ROHS Compliant | Yes |
| MSL Level | KSP2222ATF |
| Datasheet download |  KSP2222ATF.pdf |
| Part Number | KSP2222ATF |
|---|---|
| Maximum Collector Emitter Saturation Voltage | 0.3@15mA@150mA|1@50mA@500mA V |
| Maximum Power Dissipation | 625 mW |
| Lead Finish | Matte Tin |
| Maximum Collector Emitter Voltage | 40 V |
| Mounting | Through Hole |
| Supplier Package | TO-92 |
| Pin Count | 3 |
| Maximum Collector Base Voltage | 75 V |
| Maximum DC Collector Current | 0.6 A |
| Product Dimensions | 5.2 x 4.19 x 5.33 mm |
| Minimum DC Current Gain | [email protected]@10V|50@1mA@10V|75@10mA@10V|100@150mA@10V|40@500mA@10V |
| Type | NPN |
| Rad Hard | No |
| Operating Temperature | -55 to 150 °C |
| Maximum Base Emitter Saturation Voltage | 1.2@15mA@150mA|2@50mA@500mA V |
| Maximum Emitter Base Voltage | 6 V |
| Package | 3TO-92 |
| Replacement Part Number | PART-KSP2222ATF |
| Weight | Contact us |
| Country of Origin | - |
