Please contact us for more photos of FJN3303FTA
| Part Number | FJN3303FTA |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Quantity in stock | 214670 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans GP BJT NPN 400V 1.5A 3-Pin TO-92 Ammo |
| Category | Discrete Semiconductor |
| Family | Bipolar Transistor |
| ROHS Compliant | Yes |
| MSL Level | FJN3303FTA |
| Datasheet download |  FJN3303FTA.pdf |
| Part Number | FJN3303FTA |
|---|---|
| Minimum DC Current Gain | [email protected]@2V|5@1A@2V |
| Supplier Package | TO-92 |
| Maximum Emitter Base Voltage | 9 V |
| Type | NPN |
| Maximum Collector Base Voltage | 700 V |
| Pin Count | 3 |
| Maximum Power Dissipation | 650 mW |
| Maximum Collector Emitter Voltage | 400 V |
| Product Dimensions | 5.2 x 4.19 x 5.33 mm |
| Rad Hard | No |
| Mounting | Through Hole |
| Lead Finish | Matte Tin |
| Operating Temperature | -65 to 150 °C |
| Maximum Base Emitter Saturation Voltage | [email protected]@0.5A|[email protected]@1A V |
| Maximum DC Collector Current | 1.5 A |
| Maximum Collector Emitter Saturation Voltage | [email protected]@0.5A|[email protected]@1A|[email protected]@1.5A V |
| Package | 3TO-92 |
| Replacement Part Number | PART-FJN3303FTA |
| Weight | Contact us |
| Country of Origin | - |
