BC557BTA Fairchild Semiconductor

BC557BTA Images

Please contact us for more photos of BC557BTA

Part Number BC557BTA
Manufacturer Fairchild Semiconductor
Quantity in stock 674310 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Trans GP BJT PNP 45V 0.1A 3-Pin TO-92 Ammo
Category Discrete Semiconductor
Family Bipolar Transistor
ROHS Compliant Yes
MSL Level BC557BTA
Datasheet download BC557BTA.pdf
Request Quotation for BC557BTA

BC557BTA Specifications

Part Number BC557BTA
Product Dimensions 5.2 x 4.19 x 5.33 mm
Operating Temperature -65 to 150 °C
Maximum Collector Emitter Voltage 45 V
Maximum Collector Base Voltage 50 V
Maximum DC Collector Current 0.1 A
Maximum Emitter Base Voltage 5 V
Maximum Collector Emitter Saturation Voltage [email protected]@10mA|0.65@5mA@100mA V
Maximum Base Emitter Saturation Voltage [email protected]@10mA|0.9@5mA@100mA V
Type PNP
Mounting Through Hole
Pin Count 3
Minimum DC Current Gain 200@2mA@5V
Lead Finish Matte Tin
Supplier Package TO-92
Maximum Power Dissipation 500 mW
Rad Hard No
Package 3TO-92
Replacement Part Number PART-BC557BTA
Weight Contact us
Country of Origin -
