SN74LS09DR Texas Instruments

SN74LS09DR Images

Please contact us for more photos of SN74LS09DR

Part Number SN74LS09DR
Manufacturer Texas Instruments
Quantity in stock 310870 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description AND Gate 4-Element 2-IN Bipolar 14-Pin SOIC T R
Category Logic & Timing IC
Family Logic ICs
ROHS Compliant Yes
MSL Level SN74LS09DR
Datasheet download SN74LS09DR.pdf
Request Quotation for SN74LS09DR

SN74LS09DR Specifications

Part Number SN74LS09DR
Product Dimensions 8.75 x 4 x 1.5 mm
Number of Selection Inputs per Element 0
Logic Function AND
Lead Finish Gold
Max Processing Temp 260
Rad Hard No
Operating Temperature 0 to 70 °C
Maximum Operating Supply Voltage 5.25 V
Maximum Propagation Delay Time @ Maximum CL 35@5V ns
Number of Output Enables per Element 0
Mounting Surface Mount
Pin Count 14
Output Type Open Collector
MSL Level 1
Minimum Operating Supply Voltage 4.75 V
Supplier Package SOIC
Fabrication Technology Bipolar
Package 14SOIC
Replacement Part Number PART-SN74LS09DR
Weight Contact us
Country of Origin -
