Please contact us for more photos of NL17SZ00DFT2G
| Part Number | NL17SZ00DFT2G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 474960 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | NAND Gate 1-Element 2-IN CMOS 5-Pin SC-70 T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | NL17SZ00DFT2G |
| Datasheet download |  NL17SZ00DFT2G.pdf |
| Part Number | NL17SZ00DFT2G |
|---|---|
| Product Dimensions | 2.2 x 1.35 x 1 mm |
| Fabrication Technology | CMOS |
| Logic Function | NAND |
| Rad Hard | No |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Number of Output Enables per Element | 0 |
| Number of Selection Inputs per Element | 0 |
| Maximum Low Level Output Current | 32 mA |
| Minimum Operating Supply Voltage | 1.65 V |
| Operating Temperature | -40 to 85 °C |
| Maximum Operating Supply Voltage | 5.5 V |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|4.3@5V ns |
| Maximum Quiescent Current | 1 uA |
| Supplier Package | SC-70 |
| Max Processing Temp | 260 |
| Maximum High Level Output Current | -32 mA |
| Pin Count | 5 |
| Package | 5SC-70 |
| Replacement Part Number | PART-NL17SZ00DFT2G |
| Weight | Contact us |
| Country of Origin | - |
