NC7WZ08L8X Fairchild Semiconductor

NC7WZ08L8X Images

Please contact us for more photos of NC7WZ08L8X

Part Number NC7WZ08L8X
Manufacturer Fairchild Semiconductor
Quantity in stock 386080 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description AND Gate 2-Element 2-IN CMOS 8-Pin MicroPak T R
Category Logic & Timing IC
Family Logic ICs
ROHS Compliant Yes
MSL Level NC7WZ08L8X
Datasheet download NC7WZ08L8X.pdf
Request Quotation for NC7WZ08L8X

NC7WZ08L8X Specifications

Part Number NC7WZ08L8X
Rad Hard No
Operating Temperature -40 to 85 °C
Maximum Quiescent Current 1 uA
Minimum Operating Supply Voltage 1.65 V
MSL Level 1
Product Dimensions 1.6 x 1.6 x 0.5 mm
Maximum Operating Supply Voltage 5.5 V
Mounting Surface Mount
Max Processing Temp 260
Maximum Propagation Delay Time @ Maximum CL [email protected]|3.7@5V ns
Supplier Package MicroPak
Number of Selection Inputs per Element 0
Logic Function AND
Fabrication Technology CMOS
Number of Output Enables per Element 0
Pin Count 8
Package 8MicroPak
Replacement Part Number PART-NC7WZ08L8X
Weight Contact us
Country of Origin -
