MC74ACT00DTR2G ON Semiconductor

MC74ACT00DTR2G Images

Please contact us for more photos of MC74ACT00DTR2G

Part Number MC74ACT00DTR2G
Manufacturer ON Semiconductor
Quantity in stock 838060 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description NAND Gate 4-Element 2-IN CMOS 14-Pin TSSOP T R
Category Logic & Timing IC
Family Logic ICs
ROHS Compliant Yes
MSL Level MC74ACT00DTR2G
Datasheet download MC74ACT00DTR2G.pdf
Request Quotation for MC74ACT00DTR2G

MC74ACT00DTR2G Specifications

Part Number MC74ACT00DTR2G
Mounting Surface Mount
Pin Count 14
Supplier Package TSSOP
Minimum Operating Supply Voltage 4.5 V
Logic Function NAND
Operating Temperature -55 to 125 °C
Product Dimensions 5.1 x 4.5 x 1.05 mm
Maximum Quiescent Current 4 uA
MSL Level 1
Maximum Operating Supply Voltage 5.5 V
Number of Output Enables per Element 0
Number of Selection Inputs per Element 0
Maximum Propagation Delay Time @ Maximum CL 9@5V ns
Fabrication Technology CMOS
Rad Hard No
Lead Finish Gold
Max Processing Temp 260
Package 14TSSOP
Replacement Part Number PART-MC74ACT00DTR2G
Weight Contact us
