| Part Number | MC100EP01DG |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 768250 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OR NOR Gate 1-Element 4-IN ECL 8-Pin SOIC N Rail |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | MC100EP01DG |
| Datasheet download |  MC100EP01DG.pdf |
| Part Number | MC100EP01DG |
|---|---|
| Lead Finish | Matte Tin |
| Number of Output Enables per Element | 0 |
| Mounting | Surface Mount |
| Pin Count | 8 |
| Maximum Propagation Delay Time @ Maximum CL | 0.33@3V to 5.5V ns |
| MSL Level | 1 |
| Max Processing Temp | 260|265 |
| Supplier Package | SOIC N |
| Number of Selection Inputs per Element | 0 |
| Minimum Operating Supply Voltage | -3|3 V |
| Product Dimensions | 5 x 4 x 1.5 mm |
| Fabrication Technology | ECL |
| Operating Temperature | -40 to 85 °C |
| Rad Hard | No |
| Maximum Operating Supply Voltage | -5.5|5.5 V |
| Logic Function | OR/NOR |
| Package | 8SOIC N |
| Replacement Part Number | PART-MC100EP01DG |
| Weight | Contact us |
| Country of Origin | - |
