Please contact us for more photos of CD4023BPWR
| Part Number | CD4023BPWR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 582500 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | NAND Gate 3-Element 3-IN CMOS 14-Pin TSSOP T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | CD4023BPWR |
| Datasheet download |  CD4023BPWR.pdf |
| Part Number | CD4023BPWR |
|---|---|
| Minimum Operating Supply Voltage | 3 V |
| Maximum Propagation Delay Time @ Maximum CL | 250@5V|120@10V|90@15V ns |
| Fabrication Technology | CMOS |
| Number of Selection Inputs per Element | 0 |
| Maximum Quiescent Current | 5 uA |
| Max Processing Temp | 260 |
| Logic Function | NAND |
| Supplier Package | TSSOP |
| Rad Hard | No |
| Operating Temperature | -55 to 125 °C |
| Mounting | Surface Mount |
| Pin Count | 14 |
| MSL Level | 1 |
| Maximum Operating Supply Voltage | 18 V |
| Number of Output Enables per Element | 0 |
| Product Dimensions | 5.1 x 4.5 x 1.05 mm |
| Typical Quiescent Current | 0.02 uA |
| Lead Finish | Gold |
| Package | 14TSSOP |
| Replacement Part Number | PART-CD4023BPWR |
| Weight | Contact us |
| Country of Origin | - |
