74HC1G08GW125 Nexperia

74HC1G08GW125 Images

Please contact us for more photos of 74HC1G08GW125

Part Number 74HC1G08GW125
Manufacturer Nexperia
Quantity in stock 739860 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description AND Gate 1-Element 2-IN CMOS 5-Pin TSSOP T R
Category Logic & Timing IC
Family Logic ICs
ROHS Compliant Yes
MSL Level 74HC1G08GW125
Datasheet download 74HC1G08GW125.pdf
Request Quotation for 74HC1G08GW125

74HC1G08GW125 Specifications

Part Number 74HC1G08GW125
Logic Function AND
Maximum Quiescent Current 20 uA
Product Dimensions 2.25 x 1.35 x 1 mm
Fabrication Technology CMOS
Number of Selection Inputs per Element 0
Max Processing Temp 260
Maximum Propagation Delay Time @ Maximum CL 135@2V|[email protected]|23@6V ns
Minimum Operating Supply Voltage 2 V
Maximum Low Level Output Current 2.6 mA
Number of Output Enables per Element 0
Maximum Operating Supply Voltage 6 V
Supplier Package TSSOP
Rad Hard No
Mounting Surface Mount
MSL Level 1
Pin Count 5
Maximum High Level Output Current -2.6 mA
Operating Temperature -40 to 125 °C
Number of Elements per Chip 1
Lead Finish Tin
Package 5TSSOP
Replacement Part Number PART-74HC1G08GW125
Weight Contact us
Country of Origin -
