Please contact us for more photos of SN74AUC1G74DCUR
| Part Number | SN74AUC1G74DCUR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 542130 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Flip Flop D-Type Pos-Edge 1-Element 8-Pin VSSOP T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | SN74AUC1G74DCUR |
| Datasheet download |  SN74AUC1G74DCUR.pdf |
| Part Number | SN74AUC1G74DCUR |
|---|---|
| Product Dimensions | 2.3 x 2 x 0.85 mm |
| Output Signal Type | Differential |
| Supplier Package | VSSOP |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|[email protected] ns |
| Number of Channels per Chip | 1 |
| Number of Output Enables per Element | 0 |
| Number of Elements per Chip | 1 |
| Input Signal Type | Single-Ended |
| Bus Hold | No |
| Fabrication Technology | CMOS |
| Number of Element Inputs | 1 |
| Number of Element Outputs | 1 |
| Triggering Type | Positive-Edge |
| Set/Reset | Set/Reset |
| Maximum Operating Supply Voltage | 2.7 V |
| Maximum Low Level Output Current | 9 mA |
| Pin Count | 8 |
| Typical Operating Supply Voltage | 1.8|2.5 V |
| Logic Family | AUC |
| Maximum Quiescent Current | 0.01 mA |
| Polarity | Inverting/Non-Inverting |
| Logic Function | D-Type |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Maximum High Level Output Current | -9 mA |
| Propagation Delay Test Condition | 30 pF |
| Minimum Operating Supply Voltage | 0.8 V |
| Screening Level | Commercial |
| Mounting | Surface Mount |
| Lead Finish | Gold |
| Package | 8VSSOP |
| Replacement Part Number | PART-SN74AUC1G74DCUR |
| Weight | Contact us |
| Country of Origin | - |
