Please contact us for more photos of 74LVC74ABQ-Q100X
| Part Number | 74LVC74ABQ-Q100X |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 217990 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Flip Flop D-Type Pos-Edge 1-Element 14-Pin DHVQFN T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | 74LVC74ABQ-Q100X |
| Datasheet download |  74LVC74ABQ-Q100X.pdf |
| Part Number | 74LVC74ABQ-Q100X |
|---|---|
| Rad Hard | No |
| Bus Hold | No |
| Mounting | Surface Mount |
| Number of Element Outputs | 1 |
| Max Processing Temp | 260 |
| Propagation Delay Test Condition | 50 pF |
| Number of Elements per Chip | 2 |
| Input Signal Type | Single-Ended |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|[email protected]|[email protected]|[email protected]|[email protected] ns |
| Product Dimensions | 3 x 2.5 x 0.85 |
| Operating Temperature | -40 to 125 °C |
| Number of Output Enables per Element | 0 |
| Triggering Type | Positive-Edge |
| MSL Level | 1 |
| Maximum Operating Supply Voltage | 3.6 V |
| Output Signal Type | Differential |
| Number of Element Inputs | 1 |
| Pin Count | 14 |
| Maximum Low Level Output Current | 24 mA |
| Fabrication Technology | CMOS |
| Typical Operating Supply Voltage | 1.8|2.5|3.3 V |
| Screening Level | Automotive |
| Minimum Operating Supply Voltage | 1.2 V |
| Polarity | Inverting/Non-Inverting |
| Set/Reset | Set/Reset |
| Logic Function | D-Type |
| Lead Finish | Gold Over Nickel Palladium |
| Supplier Package | DHVQFN |
| Maximum High Level Output Current | -24 mA |
| Number of Channels per Chip | 2 |
| Logic Family | LVC |
| Package | 14DHVQFN |
| Replacement Part Number | PART-74LVC74ABQ-Q100X |
| Weight | Contact us |
| Country of Origin | - |
