Please contact us for more photos of SMBJ28CA
| Part Number | SMBJ28CA |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Quantity in stock | 740540 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode TVS Single Bi-Dir 28V 600W 2-Pin DO-214AA T R |
| Category | Circuit Protection |
| Family | TVS |
| ROHS Compliant | Yes |
| MSL Level | SMBJ28CA |
| Datasheet download |  SMBJ28CA.pdf |
| Part Number | SMBJ28CA |
|---|---|
| Pin Count | 2 |
| Rad Hard | No |
| Maximum Reverse Leakage Current | 5 uA |
| Mounting | Surface Mount |
| Maximum Clamping Voltage | 45.4 V |
| Lead Finish | Matte Tin |
| Max Processing Temp | 260 |
| Supplier Package | DO-214AA |
| ESD Protection | No |
| MSL Level | 1 |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage | 31.1 V |
| Maximum Reverse Stand-off Voltage | 28 V |
| Configuration | Single |
| Maximum Peak Pulse Current | 13.2 A |
| Test Current | 1 mA |
| Operating Temperature | -55 to 150 °C |
| Product Dimensions | 4.75 x 3.95 x 2.45 mm |
| Peak Pulse Power Dissipation | 600 W |
| Package | 2DO-214AA |
| Replacement Part Number | PART-SMBJ28CA |
| Weight | Contact us |
| Country of Origin | - |
