Please contact us for more photos of FSQ510MX
| Part Number | FSQ510MX |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Quantity in stock | 807150 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Power Switch 0.28A 7-Pin MLSOP T R |
| Category | Power Management IC |
| Family | Power Switch |
| ROHS Compliant | Yes |
| MSL Level | FSQ510MX |
| Datasheet download |  FSQ510MX.pdf |
| Part Number | FSQ510MX |
|---|---|
| Pin Count | 7 |
| Operating Supply Voltage Range | 20 V |
| Operating Temperature | -40 to 140 °C |
| Minimum Output Current | 0.28 A |
| Supplier Package | MLSOP |
| Supply Current | 0.8 mA |
| Maximum Power Dissipation | 1380 mW |
| Rad Hard | No |
| Number of Outputs | 1 |
| Max Processing Temp | 245 |
| Switch On Resistance | 28 Ohm |
| MSL Level | 3 |
| Mounting | Surface Mount |
| Lead Finish | Matte Tin |
| Product Dimensions | 9.4 x 6.6 x 3.6 mm |
| Package | 7MLSOP |
| Replacement Part Number | PART-FSQ510MX |
| Weight | Contact us |
| Country of Origin | - |
