Please contact us for more photos of IRM-H236T TR2
| Part Number | IRM-H236T TR2 |
|---|---|
| Manufacturer | Everlight |
| Quantity in stock | 283480 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | IR Remote Receiver 36KHz 8m 4-Pin SMD T R |
| Category | Interface IC |
| Family | IR Remote Receiver |
| ROHS Compliant | Yes |
| MSL Level | IRM-H236T TR2 |
| Datasheet download |  IRM-H236T TR2.pdf |
| Part Number | IRM-H236T TR2 |
|---|---|
| Rad Hard | No |
| Operating Supply Voltage | 2.7 to 5.5 V |
| Package Dimensions | 5.1 x 4.6 x 1.4 mm |
| Low Level Pulse Width | 800(Max) us |
| Transmission Distance | 8 m |
| Viewing Orientation | 90 ° |
| Minimum High Level Output Voltage | 2.7 V |
| Maximum Processing Temperature | 260 °C |
| Pin Count | 4 |
| Screening Level | Industrial |
| Carrier Frequency | 36 kHz |
| Supplier Package | SMD |
| High Level Pulse Width | 800(Max) us |
| Operating Temperature | -25 to 80 °C |
| Mounting | Surface Mount |
| Peak Wavelength | 940 nm |
| Moisture Sensitivity Level | 4 |
| Package | 4SMD |
| Replacement Part Number | PART-IRM-H236T TR2 |
| Weight | Contact us |
| Country of Origin | - |
