PESD2ETH-AXR Nexperia

PESD2ETH-AXR Images

Please contact us for more photos of PESD2ETH-AXR

Part Number PESD2ETH-AXR
Manufacturer Nexperia
Quantity in stock 863500 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description ESD Suppressor ESD Protection Diode 12KV 4-Pin SOT-143B T R
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level PESD2ETH-AXR
Datasheet download PESD2ETH-AXR.pdf
Request Quotation for PESD2ETH-AXR

PESD2ETH-AXR Specifications

Part Number PESD2ETH-AXR
Rad Hard No
Mounting Surface Mount
Number of Elements per Chip 2
Capacitance Value 1.8 pF
Pin Count 4
Lead Finish Tin
Direction Type Uni-Directional
Maximum Working Voltage 5.5 V
Maximum Processing Temperature 260 °C
Moisture Sensitivity Level 1
Package Dimensions 3 x 1.4 x 1.1 mm
Maximum Leakage Current 0.1 uA
Configuration Dual
Type ESD Protection Diode
Supplier Package SOT-143B
ESD Protection Voltage 12@Contact Disc kV
Package 4SOT-143B
Replacement Part Number PART-PESD2ETH-AXR
Weight Contact us
Country of Origin -
