CMF2012H3-900-2P-T EMTEK

CMF2012H3-900-2P-T Images

Please contact us for more photos of CMF2012H3-900-2P-T

Part Number CMF2012H3-900-2P-T
Manufacturer EMTEK
Quantity in stock 433690 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind Common Mode Filter 90Ohm 100MHz 300mA 0805 T R
Category Inductor
Family Inductor Surface Mount
ROHS Compliant Yes
MSL Level CMF2012H3-900-2P-T
Datasheet download CMF2012H3-900-2P-T.pdf
Request Quotation for CMF2012H3-900-2P-T

CMF2012H3-900-2P-T Specifications

Part Number CMF2012H3-900-2P-T
Impedance 90 Ohm
Pin Count 4
Type Common Mode Filter
Test Frequency 100 MHz
Maximum DC Resistance 250 mOhm
Product Dimensions 2 x 1.2 x 1.2
Supplier Package 0805
Maximum DC Current 300 mA
Rad Hard No
Package/Case 0805
Product Depth 1.2 mm
Product Height 1.2 mm
Product Length 2 mm
Replacement Part Number PART-CMF2012H3-900-2P-T
Weight Contact us
Country of Origin -
