Please contact us for more photos of TQ2SAL25ZJ
| Part Number | TQ2SAL25ZJ |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 726910 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Electromechanical Relay DPDT 2A 5VDC 178Ohm Surface Mount |
| Category | Switches and Relays |
| Family | Relays |
| ROHS Compliant | Yes |
| MSL Level | TQ2SAL25ZJ |
| Datasheet download |  TQ2SAL25ZJ.pdf |
| Part Number | TQ2SAL25ZJ |
|---|---|
| Contact Arrangement | DPDT |
| Lead Finish | Tin/Silver/Copper |
| Rad Hard | No |
| Coil Resistance | 178 Ohm |
| Operating Temperature | -40 to 85 °C |
| Product Dimensions | 14 x 11.5 x 5.6 mm |
| Mounting | Surface Mount |
| Operate Time | 4 ms |
| Relay Construction | Latching Double Coil |
| Contact Material | Silver Nickel/Gold Clad |
| Product Depth | 11.5 mm |
| Product Height | 5.6 mm |
| Product Length | 14 mm |
| Replacement Part Number | PART-TQ2SAL25ZJ |
| Weight | Contact us |
| Country of Origin | - |
