Part Number | 8-1393113-7 |
---|---|
Manufacturer | TE Connectivity |
Quantity in stock | 872440 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Electromechanical Relay DPDT 10A 24VDC 320Ohm Plain Case |
Category | Switches and Relays |
Family | Relays |
ROHS Compliant | Yes |
MSL Level | 8-1393113-7 |
Datasheet download | ![]() |
Part Number | 8-1393113-7 |
---|---|
Contact Material | Silver Cadmium Oxide |
Operating Temperature | -45 to 70 °C |
Contact Arrangement | DPDT |
Rad Hard | No |
Coil Resistance | 320 Ohm |
Mounting | Plain Case |
Product Dimensions | 38.89 x 35.71 x 55.55 mm |
Operate Time | 15 ms |
Supplier Package | Dust Cover |
Relay Construction | Non-Latching |
Product Depth | 35.71 mm |
Product Height | 55.55 mm |
Product Length | 38.89 mm |
Replacement Part Number | PART-8-1393113-7 |
Weight | Contact us |
Country of Origin | - |
