Please contact us for more photos of UP1B-4R7R
| Part Number | UP1B-4R7R |
|---|---|
| Manufacturer | Eaton |
| Quantity in stock | 654590 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Wirewound 4.7uH 20% 100KHz Ferrite 2.2A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | UP1B-4R7R |
| Datasheet download |  UP1B-4R7R.pdf |
| Part Number | UP1B-4R7R |
|---|---|
| Product Dimensions | 8.89 x 6.1 x 5 mm |
| Package/Case | 8.89 X 6.1 X 5 |
| Technology | Wirewound |
| Tolerance | 20 % |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Test Frequency | 100 kHz |
| Product Depth | 6.1 mm |
| Product Height | 5 mm |
| Product Length | 8.89 mm |
| Replacement Part Number | PART-UP1B-4R7R |
| Weight | Contact us |
| Country of Origin | - |
