HCM1104-R45-R Eaton

HCM1104-R45-R Images

Please contact us for more photos of HCM1104-R45-R

Part Number HCM1104-R45-R
Manufacturer Eaton
Quantity in stock 799160 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind High Current Power Shielded Wirewound 450nH 20% 100KHz Powdered Iron 29A T R
Category Inductor
Family Inductor Surface Mount
ROHS Compliant Yes
MSL Level HCM1104-R45-R
Datasheet download HCM1104-R45-R.pdf
Request Quotation for HCM1104-R45-R

HCM1104-R45-R Specifications

Part Number HCM1104-R45-R
Type High Current Power
Product Dimensions 11.5 x 10.3 x 4 mm
Operating Temperature -55 to 125 °C
Protection Style Shielded
Package/Case 11.5 X 10.3 X 4
Technology Wirewound
Rad Hard No
Core Material Powdered Iron
Tolerance 20 %
Test Frequency 100 kHz
Product Depth 10.3 mm
Product Height 4 mm
Product Length 11.5 mm
Replacement Part Number PART-HCM1104-R45-R
Weight Contact us
Country of Origin -
