HCM0703-4R7-R Eaton

HCM0703-4R7-R Images

Please contact us for more photos of HCM0703-4R7-R

Part Number HCM0703-4R7-R
Manufacturer Eaton
Quantity in stock 282650 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind High Current Power Shielded Wirewound 4.7uH 20% 100KHz Powdered Iron 5.5A T R
Category Inductor
Family Inductor Surface Mount
ROHS Compliant Yes
MSL Level HCM0703-4R7-R
Datasheet download HCM0703-4R7-R.pdf
Request Quotation for HCM0703-4R7-R

HCM0703-4R7-R Specifications

Part Number HCM0703-4R7-R
Type High Current Power
Package/Case 7.4 X 7 X 3
Protection Style Shielded
Operating Temperature -55 to 125 °C
Product Dimensions 7.4 x 7 x 3 mm
Core Material Powdered Iron
Technology Wirewound
Rad Hard No
Tolerance 20 %
Max Processing Temp 250
Test Frequency 100 kHz
Product Depth 7 mm
Product Height 3 mm
Product Length 7.4 mm
Replacement Part Number PART-HCM0703-4R7-R
Weight Contact us
Country of Origin -
