DRQ127-100-R Eaton

DRQ127-100-R Images

Please contact us for more photos of DRQ127-100-R

Part Number DRQ127-100-R
Manufacturer Eaton
Quantity in stock 491470 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind Power Shielded Wirewound 10.47uH 41.88uH 20% 100KHz Ferrite 6.04A 3.02A T R
Category Inductor
Family Inductor Surface Mount
ROHS Compliant Yes
MSL Level DRQ127-100-R
Datasheet download DRQ127-100-R.pdf
Request Quotation for DRQ127-100-R

DRQ127-100-R Specifications

Part Number DRQ127-100-R
Rad Hard No
Protection Style Shielded
Operating Temperature -40 to 125 °C
Package/Case 12.5 X 12.5 X 8
Test Frequency 100 kHz
Impedance
Maximum Self Resonant Frequency
Max Processing Temp 260
Type Power
Technology Wirewound
Product Dimensions 12.5 x 12.5 x 8 mm
Tolerance 20 %
Core Material Ferrite
Maximum DC Current
Maximum DC Resistance
Inductance
Minimum Quality Factor
Product Depth 12.5 mm
Product Height 8 mm
Product Length 12.5 mm
Replacement Part Number PART-DRQ127-100-R
Weight Contact us
Country of Origin -
