Part Number | BPA04B |
---|---|
Manufacturer | C&K |
Quantity in stock | 687090 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Switch DIP OFF ON SPST 4 Piano 0.1A 24VDC PC Pins 1000Cycle 2.54mm Thru-Hole Tube |
Category | Switches and Relays |
Family | Switches |
ROHS Compliant | Yes |
MSL Level | BPA04B |
Datasheet download | ![]() |
Part Number | BPA04B |
---|---|
Rad Hard | No |
Lead Finish | Gold |
Product Dimensions | 12.1 x 10.65 x 7.3 mm |
Contact Plating | Gold/Nickel |
Mechanical Life | 1000 Cycles |
Maximum DC Voltage Rating | 24 V |
Pole Throw Configuration | SPST |
Contact Material | Beryllium Copper |
Switch Configuration | OFF (ON) |
Mounting | Through Hole |
Maximum Current Rating | 0.1@5VDC A |
Actuator Style | Piano |
Operating Temperature | -20 to 85 °C |
Max Processing Temp | 260 |
Replacement Part Number | PART-BPA04B |
Weight | Contact us |
Country of Origin | - |
