| Part Number | PI5C3305LEX |
|---|---|
| Manufacturer | Diodes Incorporated |
| Quantity in stock | 857710 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Bus Switch 2-Element CMOS 2-IN 8-Pin TSSOP T R |
| Category | Logic & Timing IC |
| Family | Bus Switch |
| ROHS Compliant | Yes |
| MSL Level | PI5C3305LEX |
| Datasheet download |  PI5C3305LEX.pdf |
| Part Number | PI5C3305LEX |
|---|---|
| Maximum High Level Output Current | -120 mA |
| Configuration | 1 x 1:1 |
| Propagation Delay Test Condition | 50 pF |
| Typical Operating Supply Voltage | 5 V |
| Typical Quiescent Current | 0.1 uA |
| Operating Temperature | -40 to 85 °C |
| Logic Function | Bus Switch |
| Maximum On Resistance | 8 Ohm |
| Minimum Operating Supply Voltage | 4 V |
| Product Dimensions | 3.1 x 4.5 x 1.05 mm |
| Max Processing Temp | 260 |
| Number of Outputs per Chip | 2 |
| Lead Finish | Matte Tin |
| Supplier Package | TSSOP |
| Maximum Low Level Output Current | 120 mA |
| Rad Hard | No |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Maximum Propagation Delay Time @ Maximum CL | 0.25@5V ns |
| Maximum Operating Supply Voltage | 5.5 V |
| Fabrication Technology | CMOS |
| Pin Count | 8 |
| Number of Inputs per Chip | 2 |
| Maximum Quiescent Current | 3 uA |
| Number of Elements per Chip | 2 |
| Package | 8TSSOP |
| Replacement Part Number | PART-PI5C3305LEX |
| Weight | Contact us |
| Country of Origin | - |
