| Part Number | PI3CH480QEX |
|---|---|
| Manufacturer | Diodes Incorporated |
| Quantity in stock | 257440 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Multiplexer Demultiplexer Bus Switch 1-Element CMOS 8-IN 16-Pin QSOP T R |
| Category | Logic & Timing IC |
| Family | Bus Switch |
| ROHS Compliant | Yes |
| MSL Level | PI3CH480QEX |
| Datasheet download |  PI3CH480QEX.pdf |
| Part Number | PI3CH480QEX |
|---|---|
| Maximum High Level Output Current | -120 mA |
| Maximum On Resistance | 7 Ohm |
| Maximum Propagation Delay Time @ Maximum CL | [email protected] to 3.3V ns |
| Minimum Operating Supply Voltage | 2.25 V |
| Configuration | 4 x 2:1 |
| Maximum Operating Supply Voltage | 3.63 V |
| Operating Temperature | -40 to 85 °C |
| Number of Inputs per Chip | 8 |
| Product Dimensions | 5 x 3.99 x 1.5 mm |
| Supplier Package | QSOP |
| Pin Count | 16 |
| Max Processing Temp | 260 |
| Lead Finish | Matte Tin |
| Rad Hard | No |
| Maximum Low Level Output Current | 120 mA |
| Mounting | Surface Mount |
| Typical Operating Supply Voltage | 2.5|3.3 V |
| MSL Level | 1 |
| Number of Elements per Chip | 1 |
| Number of Outputs per Chip | 4 |
| Screening Level | Industrial |
| Fabrication Technology | CMOS |
| Logic Function | Multiplexer/Demultiplexer Bus Switch |
| Propagation Delay Test Condition | 10 pF |
| Maximum Quiescent Current | 800 uA |
| Package | 16QSOP |
| Replacement Part Number | PART-PI3CH480QEX |
| Weight | Contact us |
| Country of Origin | - |
